Model number: JDM11-6H
Supply voltage: DC12V
Input Signal: Contact,level, sensor
Max. counting speed:10 times per second (50ms)
No-power memory: 10 years min
Power consumption: 3VA max
Counting error: ≤1
Reset time: ≥0.5s
Power reset: ≥1s
Dielectric strength: 2000Vac, 50/60Hz for 1min
Insulation resistance: 100MΩ min. at 500 VDC
Operating temperature: -10 to 40 °C
